PYTES E-Box Series
Deep Cycle Batteries for long life

These are the batteries when you simply want the best,
or when they are in a location where they are difficult to maintain.
The future in batteries/Energy Storage Systems is here right now!

The PYTES E-Box Series is a deep-cycle, Lithium Ferro Phosphate (LFP) battery The Pytes V5 LFP Battery is a lithium iron phosphate (LFP) battery that provides a safe, well-designed, and high-performing battery bank solution for home energy storage. It has a nominal voltage of 51.2V and a nominal capacity of 100Ah, which translates to a nominal energy of 5.12kWh. The battery pack is compact, easy to install, maintenance-free, and can be assembled in parallel when adding more capacity. It has wide applications including residential, small commercial, industrial, and telecom systems.
The V5 provides self-heating that auto starts in cold environments and facilitates charging at below-freezing temperatures. It also has a higher 100A Maximum Continuous Charge/Discharge rate. The battery pack is stackable for up to 16 batteries without the Pytes Energy Hub.

With a lifespan of 6,000 cycles to 90% depth of discharge, these just may be the last batteries you purchase! They are maintenance-free, do not suffer thermal runaway like some lithium-ion types, and do not outgas, so they do not require any special ventilation.

Without energy storage, renewable sources of power are intermittent and unpredictable, as is utility power in emergencies and blackout scenarios in which the centralized delivery of power breaks down. LiFePo technology creates power security and resilience by taking the intermittency out of any source of power generation, including the centralized grid, fuel-based generators, wind and solar.

PYTES designs and manufactures a portfolio of clean energy storage and management solutions that are non-toxic, efficient and lightweight that do not require heat mitigation characteristic of other Lithium Ion technologies. PYTES combines lithium ferrous phosphate (LFP) chemistry with a proprietary cell architecture and battery management system (BMS) to create the most reliable, durable and scalable on-demand power solutions available in the market for a broad range of residential, commercial, military and mobile applications.

PYTES energy storage systems have been rigorously tested and successfully deployed under extreme operating conditions worldwide. In addition to offering seamless integration with all industry standard PV charge controllers and inverters, PYTES energy storage solutions are modular and scalable with a lightweight (97#) form factor backed by a 10-year warranty. PYTES 5.12KW 48V batteries energy storage products are rated at 6,000 cycles at 90% DOD, providing customers with a flexible platform from which to scale customized solutions for both off-grid and grid connected energy storage applications at the lowest lifecycle cost in the market today.

Exciting features of this new battery technology include:

• LFP is the safest, most environmentally benign Lithium Ion chemistry
• No risk of thermal runaway or fire
• No need for air conditioning, cooling, ventilation or thermal regulation
• Built in Battery Management System (BMS)
• Compatible with industry standard battery inverter/charge controllers
• Drop in replacement for lead-acid and AGM batteries
• Negligible parasitic drain – less than 1% per month
• Net zero, peak shaving and back-up power available for homes and businesses
• Supports energy cost, time-of-use and demand charge management
• Immediate access to power where critically needed, including expeditionary
and portable applications Compatible with all inverter/ charger systems
• Operating temperature range 14 to 122 degrees Fahrenheit
• Operating efficiency ≥ 95% charge/discharge efficiency rate
• Modular design, scalable from 5.12kWh to 573kWh installations
• Long cycle life – 6,000 cycles to 90% DOD
• Available in 48v
• 10 year warranty
• $1450 per each 100ah 48V battery
